Genuine Yellow Amass XT30U Male & Female Connectors XT30

Genuine Amass XT30U Male & Female Connectors - Suitable For most types of electrical project!

XT30U replace the now discontinued XT30 series of connectors. They are fully compatible with XT30 connectors.

• Maximum Voltage: DC 500v
• Maximum Current: 30A
• CR: 0.70mΩ

• Metal material: Gold plated Brass
• Plastic material: PA Polyamide / Nylon

• Usage: In excess of 1000 connections
• Cable Spec: 18AWG
• Operating temperature: -20C to 120C


See product options for different quantities and sexes (male/female).

Arguably the best quality XT30U connectors available. Made by the company that originally designed them.

Manufacturers information

High quality, genuine Amass (XT30U patent holders) connectors. Don't accept cheap low quality imitations! Suitable for all RC projects and electrical applications.

• Solid Bullet Connectors
• Perfect for applications up to and beyond 30A constant
• Low resistance for high current capacity
• Ergonomically designed and easy to grip
• Protected to avoid shorting and reverse polarity
• Superior technology suited to today’s high power applications
• Designed with convenience and reliability in mind
• Easy to un-solder and reuse

Made from high-temp Nylon and gold plated spring connectors, both included in the injection mould at the time when forming the connector. The XT30U ensures a solid high-amp connection.

These are not cheap copied XT30U plugs. These original Nylon XT30U plugs can handle over 30A current for extended periods without exceeding 80DegC thanks to their better contact surface area. The plug is also less likely to deform or melt in comparison to copied non-Nylon XT30U plugs.
